With help from celebrity investors like Dan Aykroyd and Aerosmith, House of Blues has been an iconic franchise in live music since 1992. The popular Boston location that opened in 2009 next to Fenway Park is a prime spot for concerts and private events.
A packed schedule that leaves little downtime for the repair of the club’s HVAC equipment means that reliability and ease of maintenance are extremely important factors when making purchasing decisions. In 2016, energy recovery wheels in two rooftop air-handlers became blocked after six years of exposure to airborne particulates.
Comfortable indoor environment
Although efforts were made to unclog the damaged wheels, cleaning in place was not an option due to concerns that water and cleaning fluids could damage the ductwork and ceilings below. Without working energy recovery wheels, the heating and cooling systems were forced to work overtime, at increased cost, to provide a comfortable indoor environment for the 2000-plus concert goers.
At House of Blues, airborne particles from the large crowds continue to clog the new wheels
The building’s service contractor, Cullen Mechanical, determined that the wheels were beyond repair and needed to be replaced. Cullen’s engineers knew from past experience that simply replacing the wheels without solving the cleaning problem would invite the same undesirable maintenance situation. At House of Blues, airborne particles from the large crowds, special effects vapors, and confetti would continue to clog the new wheels if the energy transfer matrix could not be periodically maintained.
Energy transfer segments
When selecting replacement wheels, Cullen prioritized both ease of installation and the ability to clean or replace the energy recovery matrix once the units were in operation. As they’ve done in the past, Cullen chose Airxchange aftermarket replacement energy recovery wheels as the best solution moving forward. Airxchange offers a unique wheel design that allows a single person to remove pie-shaped energy transfer segments with basic hand tools to be cleaned outside of the cabinet.
The refresh capability of Airxchange wheels means that they can be cleaned as often as the application dictates and counted on to last for the life of the HVAC system. In contrast to Airxchange wheels, the only cleaning or repair solution for the original wheels at House of Blues was to replace the entire wheel structure every 5-6 years, at great time and expense to the building owner.
Rooftop air-Handling units
An engineer from Airxchange presented Cullen Mechanical with a 6-8 hour wheel replacement plan
After an onsite visit, an engineer from Airxchange presented Cullen Mechanical with a 6-8 hour wheel replacement plan that minimized HVAC system downtime, ensuring that the two units would be operational for the start of that evening’s show. Because of constraints of the air-handler designs, which blocked the removal or installation of fully assembled wheels, Cullen selected replacement wheel kits from Airxchange.
These replacement kits could be easily carried through the theater and up the stairs to be quickly assembled within the cabinet of the rooftop air-handling units. In contrast, bringing any other manufacturer’s similarly sized wheel to the same rooftop would invite the cost and complexity of having a police detail shut down the sidewalk on Boston’s busy Lansdowne Street in order to operate a crane.
HVAC comfort applications
The replacement wheels were fully assembled and tested at the factory before being partially dismantled to fit into the unique access points of the air-handlers. Once the old wheels were removed by the service contractor, the two Airxchange wheels were assembled inside of the cabinets in less than four hours.
Cullen took additional steps to reduce their client’s energy costs and HVAC system downtime
Recognizing that entertainment venues often require more frequent cleanings than traditional HVAC comfort applications, Cullen took additional steps to reduce their client’s energy costs and potential HVAC system downtime. In addition to installing a fully serviceable wheel, they also ordered a complete set of replacement segments for each unit.
Energy recovery wheels
With a spare segment set on hand, operators can save time and maintenance costs by completely restoring the performance of any wheel in about 15 minutes. Once removed, dirty segments can be restored and prepared for the next cleaning cycle by soaking overnight in a cleaning solution.
After the first successful winter in operation Cullen reports that the replacement wheels have lived up to the Airxchange Replacement Solutions motto; ‘Restore, Replace, Relax.’ And though there may be plenty of sad songs performed on their stage, the facility crew at House of Blues can now whistle a happy tune when it comes to maintaining their new energy recovery wheels.
